Technical specifications
Floor space without grease tray (WxD) 450 x 500 mm
Reflector surface (ceramic stones) 4
Device height with motor 920 mm
Tubular heater 4
Max. meat weight 30 kg
Max. meat height 460 mm
Floor space with octagonal fat tray (WxD) 500 x 650 mm
Connected load 6.0 kW / 400 V/230 V / 2/N/PE/ ~50Hz
Standard series
Outputs 5.2 / 6.0 kW
Hinged doors optional
