Technical specifications
Connected load 4.5 kW / 400 V/230 V / 2/N/PE ~50Hz
Device height with motor 795 mm
Max. meat weight 15 kg
Max. meat height 340 mm
Reflector surface (ceramic stones) 3
Tubular heater 3
Floor space without grease tray (WxD) 450 x 500 mm
Floor space with octagonal fat tray (WxD) 500 x 650 mm
Standard series
Outputs 3.9 / 4.5 kW
Hinged doors optional
